Low noise 1000W BLDC Transaxle ND42-1-43.9G
The 1000W BLDC Transaxle ND42-1-43.9G offers a powerful two-stage transmission with high torque output up to 93.9Nm. It features durable alloy steel gears, low noise operation, and impressive motor efficiencies over 84%. Suitable for electric vehicles, industrial automation, and robotics, this transaxle combines strength and efficiency for diverse applications.
Introducing a robust and efficient solution for a wide range of applications – the ND42-1-43.9G 1000W BLDC Transaxle. This transaxle stands out with its two-stage transmission, offering a balance of low speed and high output torque. It features alloy steel hard tooth surface gears, ensuring longevity and reduced noise, making it a reliable choice for various uses.
Performance Advantages
- High Torque Output: The transaxle provides significant torque, up to 93.9Nm, facilitating powerful performance even in demanding situations.
- Durability: Constructed with alloy steel gears, the transaxle boasts a longer lifespan and resilience against wear and tear.
- Reduced Noise Levels: The design minimizes operational noise, ensuring a quieter and more pleasant user experience.
- Efficient Energy Use: With motor efficiencies of over 84%, this transaxle maximizes energy use, making it an economical choice.
Specifications
The ND42-1-43.9G BLDC Transaxle boasts impressive technical features that ensure its versatility and reliability across various applications.
| Specification | Detail |
|---|---|
| Model | ND42-1-43.9G |
| Rated Voltage | DC 24V/48V |
| Rated Power | 1000W |
| Transmission Ratio | 43.9, 26.35 |
| No-load Speed | 93r/min, 180r/m |
| Rated Torque | 93.9Nm, 61.66N.m |
| Motor Efficiency | 85.34%, 84.64% |
| Motor Diameter | 95.8, 95.8 |
| Electromagnetic Brake | 6Nm, 6Nm |
| Noise | ≤62, ≤62 |
| Motor Type | Brushless |
Applications
The ND42-1-43.9G is ideal for various applications, including:
- Industrial Automation: Its robust torque and efficiency make it perfect for automated machinery and industrial conveyance systems.
- Electric Vehicles: It serves as an excellent component in electric scooters, carts, and other small electric vehicles, providing reliable and efficient motion.
- Robotics: The transaxle’s precision and strength are key for robotic applications requiring controlled and powerful movement.
The ND42-1-43.9G 1000W BLDC Transaxle emerges as a highly adaptable and efficient solution, catering to a broad spectrum of applications. Its ability to deliver robust performance, even in challenging environments, is complemented by high torque and versatile dual voltage compatibility. This ensures dependable functionality. Additionally, the transaxle’s energy-efficient, low-noise design, coupled with a compact footprint, simplifies its integration into a variety of systems, ranging from electric vehicles to industrial machinery.
