150mm DC electric actuator
The 150mm DC electric actuator offers customizable travel, operates quietly at ≤60dB, and features a compact design with high thrust. It supports loads up to 4000N and provides IP54 dust and water resistance, suitable for various applications including medical, industrial, and home automation.
Share this:
Introducing the 150mm DC electric actuator, a state-of-the-art solution for intelligent applications that demand precision, durability, and efficiency. This product stands out for its ability to offer customizable travel lengths, ensuring it fits a wide range of applications. The design focuses on minimizing noise while maximizing thrust, all within a compact and visually appealing package. It excels in various environments, thanks to its IP54 protection level, ensuring it remains dustproof and waterproof. Additionally, its automatic power-off feature and stable performance make it a reliable choice for long-term use.
Advantages of the 150mm DC Electric Actuator
- Low Noise Operation: Operates at a noise level of ≤60dB, making it suitable for environments where noise is a concern.
- High Thrust with Compact Design: Despite its small size, it delivers a big thrust, making it perfect for applications with limited space.
- Cost-Efficiency: Offers a balance of performance and price, providing value for money.
- Customizable Itinerary: Allows for travel length customization to meet specific application requirements.
- Long Lifespan: Designed for durability and long service life, ensuring reliability over time.
- IP54 Protection: Guarantees a high level of protection against dust and water, suitable for outdoor applications.
- Automatic Power Off: Enhances safety by automatically turning off the power when not in operation.
Rotontek: Our Unique Advantages
Rotontek excels in providing personalized solutions and support for customization, backed by a standardized production process that ensures high-quality products. Our refinement service system is tailored to meet individual needs, whether for standard applications or unique challenges.
Applications
The versatility of the 150mm DC electric actuator makes it ideal for a wide range of applications, including but not limited to:
- Medical Beds: Enhances patient comfort and care.
- Lifting Platforms: Offers reliable lifting power for various platforms.
- Electric Lift Furniture: Ideal for adjustable desks, chairs, and other furniture.
- TV Lifts: Provides smooth and quiet operation for hidden TV systems.
- Industrial Micro-Devices: Powers a wide range of precision industrial equipment.
- Window and Door Openers: Automates the opening and closing of windows and doors.
Product Specifications
To give a clear understanding of the 150mm DC electric actuator’s capabilities, here’s a detailed table of its key specifications:
Specification | Detail |
---|---|
Rated Voltage | DC12/24/36/48V |
Rated Load | 3000N |
Max Load | 4000N |
Travel Speed | 10MM/S |
Noise Level | ≤60dB |
Stroke Length | 150mm |
Operation Temperature | -20°C~60°C |
Working System | 2S |
Protection Class | IP54 |
Wire Outlet Length | 0.2M |
Design Highlights
- Precision Manufacturing: Features a motor developed by Rotontek, ensuring efficient and powerful operation.
- Compact and Sturdy Structure: Offers a small footprint without compromising on power or durability.
- High-Quality Gear Material: Uses automobile gearbox steel for high efficiency and low noise.
- Built-In Limit Switches: Protects equipment with automatic shutdown at the end of travel.
- Efficient Screw Mechanism: Utilizes a trapezoidal screw for quiet and smooth operation.
The 150mm DC electric actuator from Rotontek embodies innovation, efficiency, and reliability, making it an excellent choice for various applications. Its blend of customizable features, robust design, and performance efficiency ensures it meets the needs of demanding environments. For specific requirements or customization inquiries, Rotontek encourages direct contact with our sales and engineering team to explore personalized solutions.
